SC connector, UPC fiber optic connector , Plastic

SC UPC/APC plastic fiber optic connectorDescription:Low insertion loss and high return lossGood reuse performanceSC UPC/APC plastic fiber optic connector applicationOptical fiber communication systemFiber Access NetworkCATVOptical fiber data communicationFiber optic test equipmentSpecificationsItemU...

Inquiry

Product Attributes

ConnectorType:FC,ST,SC,LC
PolishingType:UPC
PortType:Simplex,duplex
FiberType:Single-mode,Muti-mode
ProductModel:SCFiberOpticConnector

Product Technical Parameters

Product Description

SC UPC/APC plastic fiber optic connectorDescription:

Low insertion loss and high return loss
Good reuse performance

SC UPC/APC plastic fiber optic connector application

Optical fiber communication system
Fiber Access Network
CATV
Optical fiber data communication
Fiber optic test equipment

Specifications

Item	UPC		APC
	Φ0.125mm	Φ0.25mm	Φ0.125mm	Φ0.25mm
Radius of Curve(mm)	7~25	10~25	5~12	5~12
Return Loss(dB)	50	50	55	55
Apex Offset(um)	≤50
Fiber Height(nm)	-0.5
Polishing Angle(°)	8±0.3
Testing wavelength(nm)	1310&1550
Insertion Loss	≦0.3dB
Operating temperature	-40℃~ +80℃
Cable diameter	0.9mm, 2mm, 3mm
Service life	N＞1000
Dust Cap	LDPE
Connectors type	FC, ST, SC, LC
Polishing type	UPC, APC
Fiber type	Single-mode, Muti-mode
Port type	Simple, double
Application	drop cable/patch cords/pigtail

application

Fiber-optic-access-networks
CATV
Fiber-optic-communications

Case

Kajian Kes Projek Komunikasi Koridor Talian Kuasa Angola | Bekalan OPGW sebagai Tulang Belakang + Sokongan Portfolio Kabel Gentian Optik Luaran

Turkey：YRTFiber's Metropolitan Fiber Network Modernization in Turkey

YRTFiber's Metropolitan Area Network Upgrade in Indonesia

Zambia : High-Performance Outdoor Fiber Optic Cable Supply by yrtfiber

OVERVIEW Download

Keywords: No keywords yet

ST connector UPC plastic fiber optic connectors

LC connector ， UPC/APC ，single mode， lc fiber optic connecto
