Sliding Rail ODF Distribution Frame for Efficient, Scalable Fiber Management

Slide Rail Type ODF Distribution Frame

Flexible Slide‑Rail Design for Superior Accessibility

The sliding rail structure allows the ODF module to be smoothly pulled out for easy access during installation, maintenance, or upgrades—eliminating the need to disassemble entire racks and saving valuable time. The layered tray design supports front/rear or upper/lower slide configurations to adapt to varying cabinet depths.

High‑Density Modularity and Expansion

This frame supports high port counts with flexible configurations—SC, LC, MPO interfaces, simplex or duplex adapters, and customizable port arrangements. Modular units can be independently added or removed to scale fiber capacity on demand.

Robust Materials & Precision Engineering

Constructed from cold‑rolled steel or aluminum alloy with anti‑corrosion surface treatment, the frame delivers high load‑bearing capacity and durability. Laser‑cut precision ensures accurate port alignment and optimal signal integrity.

Smart Fiber Management Features

Built‑in bending radius controls (≥ 30 mm), fiber retaining clips, and visual labeling strips simplify orderly cable routing and identification. Transparent or clam‑shell doors offer visibility and protection during fiber operations.

Wide Compatibility & Application Range

The sliding rail ODF supports both single‑mode and multi‑mode fibers, compatible with SC, LC, FC, ST, and MPO/MTP connectors. Designed for standard 19‑inch racks (ANSI/EIA, ETSI), it fits seamlessly into data centers, telecom rooms, enterprise networks, and FTTx deployment scenarios.

Enhanced Protection & System Reliability

The enclosed metal construction offers electromagnetic interference (EMI) shielding. Optional IP20/IP55 ratings provide dust and water resistance for industrial or challenging environments, bolstering long-term reliability.
